Bentork 16S7P NMC Battery Pack &amp; Smart BMS — 3D Simulation

Prudence Malinki

MarkMonitor Inc.

edgeone.app


// ========== BATTERY MODEL ==========
const PK={S:16,P:7,cells:112,Vnom:57.6,Vmax:67.2,Vmin:48.0,cap:32,maxId:64,maxIc:32};
const TH={R0:0.085,Rp1:0.022,Cp1:1800,Rp2:0.018,Cp2:18000,EaRg:3000};
function ocv(soc){const s=Math.max(0,Math.min(1,soc));return(3.0+1.2*s-0.8*(s*s-s)+0.15*Math.sin(Math.PI*s))*PK.S;}
function r0T(T){return TH.R0*Math.exp(TH.EaRg*(1/(T+273.15)-1/298.15));}

let S={soc:0.80,Vrc1:0,Vrc2:0,Tbat:30,Tamb:30,Iload:30,dm:'throttle',spd:10,t:0,eUsed:0};
let cityPh=0;

function sim(dtr){
  const dt=dtr*S.spd;
  let I;
  if(S.dm==='throttle') I=S.Iload;
  else if(S.dm==='cruise') I=S.Iload*0.45;
  else if(S.dm==='coast') I=S.Iload*0.05;
  else if(S.dm==='regen') I=-Math.min(S.Iload,PK.maxIc);
  else if(S.dm==='stop') I=0;
  else if(S.dm==='city'){
    cityPh=(cityPh+dt*0.15)%(2*Math.PI);
    const w=Math.sin(cityPh);
    I=w>0.3?S.Iload*0.7:w<-0.3?-Math.min(S.Iload*0.3,PK.maxIc):S.Iload*0.05;
  }
  const ov=ocv(S.soc);
  if(ov>=PK.Vmax&&I<0) I=0;
  if(ov<=PK.Vmin&&I>0) I=0;
  I=Math.max(-PK.maxIc,Math.min(PK.maxId,I));
  if(S.Tbat>45) I*=Math.max(0,1-(S.Tbat-45)/15);
  const r0=r0T(S.Tbat);
  S.Vrc1+=(I*TH.Rp1-S.Vrc1)/(TH.Rp1*TH.Cp1)*dt;
  S.Vrc2+=(I*TH.Rp2-S.Vrc2)/(TH.Rp2*TH.Cp2)*dt;
  const Vt=ov-I*r0-S.Vrc1-S.Vrc2;
  S.soc=Math.max(0,Math.min(1,S.soc-(I*dt)/(PK.cap*3600)));
  const Pl=I*I*r0+S.Vrc1*I+S.Vrc2*I;
  S.Tbat+=(Pl-8*(S.Tbat-S.Tamb))/5000*dt;
  S.eUsed+=Math.abs(Vt*I*dt/3600);
  S.t+=dt;
  return{Vt,ov,I,r0,Pl};
}

// ========== THREE.JS ==========
let scene,cam,ren,bg,cells=[],bleds=[],particles=[];
let drag=false,pm={x:0,y:0},rx=0.35,ry=-0.5;

function init3D(){
  const c=document.getElementById('canvas-area');
  scene=new THREE.Scene();
  cam=new THREE.PerspectiveCamera(40,c.clientWidth/c.clientHeight,0.1,100);
  cam.position.set(0,5,18);cam.lookAt(0,0,0);
  ren=new THREE.WebGLRenderer({canvas:document.getElementById('three-canvas'),antialias:true,alpha:true});
  ren.setSize(c.clientWidth,c.clientHeight);ren.setPixelRatio(Math.min(window.devicePixelRatio,2));

  scene.add(new THREE.AmbientLight(0x334466,0.6));
  const dl=new THREE.DirectionalLight(0xffffff,0.8);dl.position.set(5,10,5);scene.add(dl);
  const pl1=new THREE.PointLight(0x00d4ff,0.4);pl1.position.set(-5,5,-5);scene.add(pl1);
  const pl2=new THREE.PointLight(0xff8c00,0.3);pl2.position.set(5,3,5);scene.add(pl2);

  const gr=new THREE.GridHelper(20,20,0x002244,0x001122);gr.position.y=-3.2;scene.add(gr);
  bg=new THREE.Group();scene.add(bg);
  buildPack();buildBMS();initPart();

  const cv=document.getElementById('three-canvas');
  cv.addEventListener('mousedown',e=>{drag=true;pm={x:e.clientX,y:e.clientY};});
  cv.addEventListener('mousemove',e=>{if(drag){ry+=(e.clientX-pm.x)*0.005;rx+=(e.clientY-pm.y)*0.005;rx=Math.max(-1,Math.min(1,rx));pm={x:e.clientX,y:e.clientY};}});
  cv.addEventListener('mouseup',()=>drag=false);cv.addEventListener('mouseleave',()=>drag=false);
  cv.addEventListener('wheel',e=>{cam.position.z+=e.deltaY*0.01;cam.position.z=Math.max(8,Math.min(30,cam.position.z));});
  cv.addEventListener('touchstart',e=>{drag=true;pm={x:e.touches[0].clientX,y:e.touches[0].clientY};},{passive:true});
  cv.addEventListener('touchmove',e=>{if(drag&&e.touches.length===1){ry+=(e.touches[0].clientX-pm.x)*0.005;rx+=(e.touches[0].clientY-pm.y)*0.005;rx=Math.max(-1,Math.min(1,rx));pm={x:e.touches[0].clientX,y:e.touches[0].clientY};}},{passive:true});
  cv.addEventListener('touchend',()=>drag=false);
  window.addEventListener('resize',()=>{cam.aspect=c.clientWidth/c.clientHeight;cam.updateProjectionMatrix();ren.setSize(c.clientWidth,c.clientHeight);});
}

function buildPack(){
  cells=[];const w=0.32,h=1.6,g=0.07;
  const pw=PK.P*(w+g)-g,pd=PK.S*(w+g)-g;
  // Case
  const cg=new THREE.BoxGeometry(pw+0.5,h+0.3,pd+0.5);
  bg.add(new THREE.Mesh(cg,new THREE.MeshPhongMaterial({color:0x0a1a2e,transparent:true,opacity:0.18,specular:0x00d4ff,shininess:30,side:THREE.BackSide})));
  bg.add(new THREE.LineSegments(new THREE.EdgesGeometry(cg),new THREE.LineBasicMaterial({color:0x00d4ff,transparent:true,opacity:0.3})));
  // Cells
  for(let s=0;s<PK.S;s++)for(let p=0;p<PK.P;p++){
    const m=new THREE.Mesh(new THREE.CylinderGeometry(w/2,w/2,h,8),
      new THREE.MeshPhongMaterial({color:0x00cc66,emissive:0x003311,specular:0x44ffaa,shininess:60,transparent:true,opacity:0.85}));
    m.position.x=(p-PK.P/2+0.5)*(w+g);m.position.z=(s-PK.S/2+0.5)*(w+g);
    m.userData={s:s,p:p};cells.push(m);bg.add(m);
    const cp=new THREE.Mesh(new THREE.CylinderGeometry(w/4,w/3,0.06,8),
      new THREE.MeshPhongMaterial({color:0xffaa00,emissive:0x442200,shininess:80}));
    cp.position.copy(m.position);cp.position.y=h/2+0.03;bg.add(cp);
  }
  // Bus bars
  for(let s=0;s<PK.S-1;s++){
    const b=new THREE.Mesh(new THREE.BoxGeometry(pw,0.02,0.03),
      new THREE.MeshPhongMaterial({color:0xff6600,emissive:0x331100,shininess:100}));
    b.position.y=h/2+0.07;b.position.z=(s-PK.S/2+1)*(w+g)-(w+g)/2;bg.add(b);
  }
  // Terminals
  const tg=new THREE.CylinderGeometry(0.11,0.11,0.22,12);
  const tp=new THREE.Mesh(tg,new THREE.MeshPhongMaterial({color:0xff3333,emissive:0x660000}));
  const tn=new THREE.Mesh(tg,new THREE.MeshPhongMaterial({color:0x3333ff,emissive:0x000066}));
  tp.position.set(pw/2+0.35,h/2+0.18,-pd/2);tn.position.set(-pw/2-0.35,h/2+0.18,pd/2);
  bg.add(tp);bg.add(tn);
}

function buildBMS(){
  const bd=new THREE.Mesh(new THREE.BoxGeometry(3.2,0.07,2),
    new THREE.MeshPhongMaterial({color:0x0a3320,emissive:0x001a10,specular:0x00ff44}));
  bd.position.set(0,-2.5,0);bg.add(bd);
  for(let i=0;i<7;i++){const t=new THREE.Mesh(new THREE.BoxGeometry(2.8,0.012,0.012),
    new THREE.MeshPhongMaterial({color:0xcc8800,emissive:0x442200}));
    t.position.set(0,-2.44,-0.75+i*0.22);bg.add(t);}
  bleds=[];
  for(let i=0;i<5;i++){
    const l=new THREE.Mesh(new THREE.SphereGeometry(0.05,6,6),
      new THREE.MeshPhongMaterial({color:0x00ff88,emissive:0x00ff88,emissiveIntensity:0.5,transparent:true,opacity:0.9}));
    l.position.set(-1+i*0.5,-2.4,-0.75);bleds.push(l);bg.add(l);
  }
  for(let i=0;i<3;i++){const ch=new THREE.Mesh(new THREE.BoxGeometry(0.3,0.05,0.2),
    new THREE.MeshPhongMaterial({color:0x111111,specular:0x444444}));
    ch.position.set(-0.5+i*0.5,-2.44,0.35);bg.add(ch);}
  // Flat ribbon cable
  const rb=new THREE.Mesh(new THREE.BoxGeometry(0.8,1.3,0.02),
    new THREE.MeshPhongMaterial({color:0x444444,transparent:true,opacity:0.3}));
  rb.position.set(0,-1.55,0);bg.add(rb);
}

// Particles
function initPart(){
  const pg=new THREE.SphereGeometry(0.035,4,4);
  for(let i=0;i<40;i++){
    const pm=new THREE.MeshBasicMaterial({color:0x00ff88,transparent:true,opacity:0});
    const p=new THREE.Mesh(pg,pm);
    p.userData={ph:Math.random()*Math.PI*2,spd:0.4+Math.random()*1.2,
      sx:(Math.random()-0.5)*1.8,sz:(Math.random()-0.5)*2.5};
    p.position.set(0,-10,0);particles.push(p);bg.add(p);
  }
}

function updPart(I){
  const dis=I>0.5,chg=I<-0.5,inten=Math.min(Math.abs(I)/PK.maxId,1);
  particles.forEach((p,i)=>{
    if(!dis&&!chg){p.material.opacity=0;return;}
    if(i>=Math.floor(inten*40)){p.material.opacity=0;return;}
    p.userData.ph+=0.02*p.userData.spd;
    const pr=(p.userData.ph%(Math.PI*2))/(Math.PI*2);
    p.material.color.setHex(dis?0x00ff88:0x00d4ff);
    p.position.y=dis?(-2.5+pr*4):(1.5-pr*4);
    p.position.x=p.userData.sx*0.4;p.position.z=p.userData.sz*0.25;
    let op=0.3+inten*0.6;
    if(pr<0.1) op*=pr/0.1;if(pr>0.9) op*=(1-pr)/0.1;
    p.material.opacity=op;
  });
}

function updCells(soc,I){
  cells.forEach(m=>{
    const imb=Math.sin(m.userData.s*0.5+S.t*0.01)*0.02;
    const cs=Math.max(0,Math.min(1,soc+imb)),h=cs*0.33;
    const ei=Math.abs(I)/PK.maxId*0.3;
    m.material.color.setHSL(h,0.8,0.35+ei);
    m.material.emissive.setHSL(I<-1?0.55:h,I<-1?0.8:0.5,0.05+ei*0.5);
  });
}

// ========== CHARTS ==========
let ch={};const MP=150;
function initCh(){
  const mk=(id,col,mn,mx)=>new Chart(document.getElementById(id),{
    type:'line',data:{labels:[],datasets:[{data:[],borderColor:col,backgroundColor:col+'12',
      borderWidth:1.5,pointRadius:0,fill:true,tension:0.3}]},
    options:{responsive:true,maintainAspectRatio:false,animation:false,
      scales:{x:{display:false},y:{min:mn,max:mx,
        ticks:{color:'rgba(255,255,255,0.18)',font:{family:'Share Tech Mono',size:7},maxTicksLimit:4},
        grid:{color:'rgba(255,255,255,0.03)'}}},
      plugins:{legend:{display:false}}}});
  ch.v=mk('ch-v','#00d4ff',44,70);ch.i=mk('ch-i','#ff8c00',-35,70);
  ch.s=mk('ch-s','#00ff88',0,100);ch.t=mk('ch-t','#ff3366',20,65);
}
function pushCh(Vt,I,soc,tmp){
  const t=(S.t/60).toFixed(1);
  const pu=(c,v)=>{c.data.labels.push(t);c.data.datasets[0].data.push(v);
    if(c.data.labels.length>MP){c.data.labels.shift();c.data.datasets[0].data.shift();}c.update();};
  pu(ch.v,Vt);pu(ch.i,I);pu(ch.s,soc*100);pu(ch.t,tmp);
}

// ========== SOC RING ==========
function drawSOC(soc){
  const c=document.getElementById('soc-cv'),ctx=c.getContext('2d');
  const w=c.width,h=c.height,cx=w/2,cy=h/2,r=42;
  ctx.clearRect(0,0,w,h);
  ctx.beginPath();ctx.arc(cx,cy,r,-Math.PI/2,Math.PI*2-Math.PI/2);
  ctx.strokeStyle='rgba(255,255,255,0.05)';ctx.lineWidth=6;ctx.stroke();
  const a=soc*Math.PI*2,g=ctx.createLinearGradient(0,0,w,h);
  if(soc>0.5){g.addColorStop(0,'#00ff88');g.addColorStop(1,'#00d4ff');}
  else if(soc>0.2){g.addColorStop(0,'#ffdd00');g.addColorStop(1,'#ff8c00');}
  else{g.addColorStop(0,'#ff3366');g.addColorStop(1,'#ff0000');}
  ctx.beginPath();ctx.arc(cx,cy,r,-Math.PI/2,-Math.PI/2+a);
  ctx.strokeStyle=g;ctx.lineWidth=6;ctx.lineCap='round';ctx.stroke();
  const el=document.getElementById('soc-disp');
  el.textContent=(soc*100).toFixed(0)+'%';
  el.style.color=soc>0.5?'#00ff88':soc>0.2?'#ffdd00':'#ff3366';
}

// ========== BMS ==========
function updBMS(Vt,I){
  const sL=(id,st)=>{document.getElementById('bl-'+id).className='bms-d '+st;};
  sL('ovp',Vt>=PK.Vmax*0.98?(Vt>=PK.Vmax?'trip':'warn'):'ok');
  sL('uvp',Vt<=PK.Vmin*1.05?(Vt<=PK.Vmin?'trip':'warn'):'ok');
  sL('ocp',Math.abs(I)>(I>0?PK.maxId*0.9:PK.maxIc*0.9)?'warn':'ok');
  sL('otp',S.Tbat>40?(S.Tbat>50?'trip':'warn'):'ok');
  sL('scp',Math.abs(I)>PK.maxId*1.5?'trip':'ok');
  bleds.forEach((l,i)=>{
    const ids=['ovp','uvp','ocp','otp','scp'];
    const el=document.getElementById('bl-'+ids[i]);
    if(el.classList.contains('trip')){l.material.color.setHex(0xff3366);l.material.emissive.setHex(0xff3366);l.material.emissiveIntensity=1.5;}
    else if(el.classList.contains('warn')){l.material.color.setHex(0xffdd00);l.material.emissive.setHex(0xffdd00);l.material.emissiveIntensity=0.8;}
    else{l.material.color.setHex(0x00ff88);l.material.emissive.setHex(0x00ff88);l.material.emissiveIntensity=0.3;}
  });
}

// ========== CONTROLS ==========
function setDrv(m){
  S.dm=m;
  document.querySelectorAll('.drv-btn').forEach(b=>b.className='drv-btn');
  const btn=document.getElementById('btn-'+m);btn.classList.add('on');
  if(m==='regen') btn.classList.add('rg');
  if(m==='stop') btn.classList.add('brk');
}
function uCur(v){S.Iload=+v;document.getElementById('l-cur').textContent=v+'A';}
function uSoc(v){S.soc=v/100;document.getElementById('l-soc').textContent=v+'%';}
function uTmp(v){S.Tamb=+v;S.Tbat=+v;document.getElementById('l-tmp').textContent=v+'°C';}
function uSpd(v){S.spd=+v;document.getElementById('l-spd').textContent=v+'×';}

function updFlow(I,Vt){
  const bar=document.getElementById('ef'),ic=document.getElementById('efi'),tx=document.getElementById('eft');
  const dt=document.getElementById('mdot'),mn=document.getElementById('mname'),mp=document.getElementById('mpow');
  const modes={throttle:'THROTTLE',cruise:'HIGHWAY',city:'CITY STOP-GO',regen:'REGEN BRAKE',coast:'COASTING',stop:'STOPPED'};
  mn.textContent=modes[S.dm]||'';mp.textContent=Math.abs(Vt*I).toFixed(0)+' W';
  if(I<-0.5){bar.className='ef chg';ic.textContent='⚡←';tx.textContent='CHARGING · '+Math.abs(I).toFixed(0)+'A · '+Math.abs(Vt*I).toFixed(0)+'W';tx.style.color='var(--cyan)';dt.className='m-dot chg';}
  else if(I>0.5){bar.className='ef dis';ic.textContent='⚡→';tx.textContent='DISCHARGING · '+I.toFixed(0)+'A · '+(Vt*I).toFixed(0)+'W';tx.style.color='var(--green)';dt.className='m-dot dis';}
  else{bar.className='ef idle';ic.textContent='⏸';tx.textContent='IDLE · NO LOAD';tx.style.color='rgba(255,255,255,0.35)';dt.className='m-dot idle';}
}

// ========== MAIN LOOP ==========
let lt=performance.now(),cc=0;
function anim(now){
  requestAnimationFrame(anim);
  const dt=Math.min((now-lt)/1000,0.05);lt=now;
  const r=sim(dt);
  if(!drag) ry+=0.0008;
  bg.rotation.x=rx;bg.rotation.y=ry;
  updCells(S.soc,r.I);updPart(r.I);
  ren.render(scene,cam);
  // UI
  document.getElementById('rv').textContent=r.Vt.toFixed(2)+'V';
  document.getElementById('ro').textContent=r.ov.toFixed(2)+'V';
  document.getElementById('ri').textContent=r.I.toFixed(1)+'A';
  document.getElementById('rp').textContent=(r.Vt*r.I).toFixed(0)+'W';
  document.getElementById('rc').textContent=(r.Vt/PK.S).toFixed(3)+'V';
  document.getElementById('rt').textContent=S.Tbat.toFixed(1)+'°C';
  document.getElementById('re').textContent=S.eUsed.toFixed(1)+'Wh';
  document.getElementById('rr').textContent=r.r0.toFixed(4)+'Ω';
  document.getElementById('cv').textContent=r.Vt.toFixed(1)+'V';
  document.getElementById('ci').textContent=r.I.toFixed(0)+'A';
  document.getElementById('cs').textContent=(S.soc*100).toFixed(1)+'%';
  document.getElementById('ct').textContent=S.Tbat.toFixed(1)+'°C';
  drawSOC(S.soc);updBMS(r.Vt,r.I);updFlow(r.I,r.Vt);
  cc++;if(cc%8===0) pushCh(r.Vt,r.I,S.soc,S.Tbat);
}

// INIT
init3D();initCh();drawSOC(S.soc);
// Seed charts so they're not empty
for(let i=0;i<30;i++){const r=sim(0.05);pushCh(r.Vt,r.I,S.soc,S.Tbat);}
anim(performance.now());


Requests	IP Address	Location	AS Autonomous System
3	142.251.143.106	United States	AS15169Google LLC
2	104.16.175.226	United States	AS13335Cloudflare, Inc.
2	142.251.141.131	United States	AS15169Google LLC
2	104.17.24.14	United States	AS13335Cloudflare, Inc.
2	43.152.26.58	Singapore	AS139341ACE
11	5	-	-

Security Scan Report: conservation-azure-zdwkcbnc4n-gfwwkys2ad.edgeone.app

Summary

AI Security Verdict

Safe Website

Safety Factors

Details

Screenshot

Page Load Overview

Language Analysis

Primary Language

Detection Details

Website Classification

Primary Category

All Detected Categories

Detected Features

Domain & IP Information

Detected Technologies4

Content Similarity HashesFor malware variant detection

TLSH (Trend Micro Locality Sensitive Hash)

ssdeep (Context Triggered Piecewise Hashing)

sdhash (Similarity Digest Hashing)

Image Hashes

Perceptual Hashes

Other Hashes

Scan History
